31 16 15 0
Address: 0x109000
Reset Value: 0x0
Note: NONE
REG_TRACK Definition
Read Only
Track Value
Tag Value
Bit 16 - 31: These bits are set to indicate the tracking value for the tracked graphics objects.
The coprocessor caculates how much the current touching points take within the predefined
range. Please check the CMD_TRACK for more details.
Bit0 - 15: These bits are set to indicate the tag value of a graphics object which is being
touched.
3.5 Miscellaneous Registers
In this chapter, the miscellaneous registers covers backlight control, interrupt, GPIO, and
other functionality registers.
Register Definition 58 REG_PWM_DUTY Definition
