31 8 7 0
R/W
REG_PWM_DUTY Definition
Address: 0x1024C4
Reset Value: 0x80
Note:
Bit 0 - 7 : These bits define the backlight PWM output duty cycle. The valid
range is from 0 to 128. 0 means backlight complete off, 128 means backlight in
max brightness.
