Register Definition 25 REG_TOUCH_DIRECT_XY
RO Reserved Reserved
31 26 25 16 15 10 9 0
REG_TOUCH_DIRECT_XY Definition
Bit 0 - 9 : The 10 bit ADC value for Y coordinate
Bit 16-25: The 10 bit ADC value for X coordinate.
Bit 31 : If this bit is zero, it means a touch is being sensed and the two
fields above contains the sensed data. If this bit is one, it means no
touch is being sensed and the data in the two fields above shall be
ignored.
