Register Definition 33 REG_TOUCH_TAG_XY Definition
31 16 15 0
RO
RO
REG_TOUCH_TAG_XY Definition
Address: 0x102514
Reset Value: 0
Note: Host can read this register to check the coordinates used by the touch
engine to update the tag register REG_TOUCH_TAG.
Bit 0 - 15 : The value of these bits are the Y coordinates of the touch screen,
which was used by the touch engine to look up the tag result.
Bit 16 - 31: The value of these bits are X coordinates of the touch screen, which
was used by the touch engine to look up the tag result.
