Register Definition 39 REG_TOUCH_SETTLE Definition
31 4 3 0
REG_TOUCH_SETTLE Definition
Address: 0x1024FC
Reset Value: 0x3
Note: .
Bit 0 - 3 : These bits control the touch screen settle time , in the unit of 6 clocks. The
default value is 3, meaning the settle time is 18 (3*6) system clock cycles.
R/W
Reserved
Register Definition 40 REG_TOUCH_CHARGE Definition
31 16 15 0
REG_TOUCH_CHARGE Definition
Address: 0x1024F8
Reset Value: 0x1770
Note: .
Bit 0 - 15 : These bits control the touch-screen charge time, in the unit of 6 system
clocks. The default value after reset is 6000, i.e. the charge time will be 6000*6 clock
cycles.
R/W
Reserved
