143
12
Figure 22
19. Insert governor spring into original hole in
governor lever.
NOTICE: Governor spring must be installed in
correct hole in governor control lever by engine
model (Figure 23).
• Model 430400 - Top Hole
• Model 580400 - Bottom Hole
Figure 23
Adjust Governor
1. Move governor control lever (Figure 24) up to
end of travel and hold in this position
(throttle wide open).
2. Rotate governor shaft clockwise to end of
travel.
3. Torque governor nut to value listed in Section
14 - Engine Specifications.
Figure 24
