Brooks Automation
278580 Revision A 81
LF80C ZeniD RFID Reader 7 Operation
Product Manual 7.3 Operation of SECS Protocol
Description: Identifier for an attribute for a specific type of object.
CIDRW attribute definitions:
"Configuration"… Number of heads
"AlarmStatus” Current CIDRW sub-status of ALARM STATUS
"OperationalStatus" Current CIDRW sub-status of OPERATING
STATUS
"SoftwareRevisionLevel" Revision (version) of software - 8-byte
maximum
"CarrierIDOffset" Offset of CID in CID field (MID area)
"CarrierIDLength" Length of CID in CID field (MID area)
"ECID_00" → parameter 0 -
Î
Gateway ID
"ECID_01" → parameter 1 -
Î
Baudrate
"ECID_02" → parameter 2 -
Î
Inter-character timeout T1
"ECID_03" → parameter 3 -
Î
Block protocol timeout T2
"ECID_04" → parameter 4 -
Î
Reply timeout T3
"ECID_05" → parameter 5 -
Î
Inter-block timeout T4
"ECID_06" → parameter 6 -
Î
Retry limit RTY
"ECID_07" → parameter 7 -
Î
TARGETID high byte
"ECID_08" → parameter 8 -
Î
TARGETID low byte
"ECID_09" → parameter 9 -
Î
Heartbeat time
1)
"ECID_11" → parameter 11 -
Î
ReaderID
"ECID_12" → parameter 12 -
Î
HeadID
"ECID_20" → parameter 20 -
Î
Sensor delay for presence sensor
"ECID_22" → parameter 22 -
Î
Sensor-triggered action for presence
sensor
"ECID_23" → parameter 23 -
Î
Triggered read frequency
"ECID_24" → parameter 24 -
Î
r/w max repeat
"ECID_25" → parameter 25 -
Î
Transponder type
"ECID_26" → parameter 26 -
Î
Sensor activity
"ECID_27" → parameter 27 -
Î
Watchport for presence sensorr
"ECID_28" → parameter 28 -
Î
Transmitter level (read mode)
"ECID_29" → parameter 29 -
Î
Transponder load duration (read mode)
"ECID_30" → parameter 30 -
Î
r/w synchronize
"ECID_31" → parameter 31 -
Î
Auto-adjust value (read mode)
"ECID_32" → parameter 32 -
Î
Auto-adjust value (write mode)
"ECID_33" → parameter 33 -
Î
Automatic antenna adjustment
"ECID_34" → parameter 34 -
Î
Sensor type for presence sensor
"ECID_35" → parameter 35 -
Î
Special features
"ECID_36" → parameter 36 -
Î
Lock membrane keyboard
"ECID_37" → parameter 37 -
Î
MID area
"ECID_38" → parameter 38 -
Î
Test after software reset
"ECID_39" → parameter 39 -
Î
Transmitter level (write mode)
"ECID_40" → parameter 40 -
Î
Transponder load duration (write mode)
ATTRID
Format:
A[max25]
