Brooks LF80C - Page 96

Brooks Automation
84 278580 Revision A
7 Operation LF80C ZeniD RFID Reader
7.3 Operation of SECS Protocol Product Manual
Description Used to identify the data requested.
The DATASEG corresponds to the page number (PAGEID) of multipage,
read/only and read/write transponders.
"00" First page of any type of transponder or first page of
DATA
area in case of a multipage transponder.
Multipage-transponder (page 1 to page 17):
Start the reading or writing on the following page of a multipage
transponder:
...
"01" page 1 "81" Locked page 1
... ...
"11" page 17 "91" Locked page 17
Read/only transponder "F0" Read only the one page
Read/write transponder "F1" Read or write only the one page
Where used S18F5, S18F7
Acknowledge code for new reader constant
0 ... Parameter was set successfully
1 ... Parameter could not be set
Where used S2F16
Parameter number of reader (see data item ECV)
Where used S2F13, S2F15
Reader parameter definition.
The values are displayed as decimal values, see
Î
Parameters.
DATASEG Format:A[2]
EAC Format: B[1]
ECID Format: U1
ECV Format: U1
