Brooks Automation
278580 Revision A 85
LF80C ZeniD RFID Reader 7 Operation
Product Manual 7.3 Operation of SECS Protocol
3 ... external LED
4 ... OK
5 ... Error
6 ... Antenna
7 ... Output
12 ... Read
13 ... Write
14 ... Tuning
Where used S18F13
Description Status request value
"On" Reader is on
"Off" Reader is off
"Flash" LED flashes
Where used S18F13
Equipment model number.
Where used S1F2
Material format code.
20: The material port number corresponds to the sensor number and
status
Where used S3F5, S3F7
SECS message block header associated with message block in error.
Where used S9F1, S9F3, S9F5, S9F7, S9F9
LEDNR Format: A[]
LEDSTATE Format: A[]
MDLN Format: A[6]
MF Format: B[1]
MHEAD Format: B[10]
