Polycold Cryochiller Installation
Installation and Operation Manual Move to Location
Brooks Automation
214072 Revision B 4-7
Move to Location
NOTE: If the unit includes the Lifting Ring option, refer to Appendix B: Lifting Rings (Optional) on
page 12-3
If the unit includes casters, refer to 185304, Install Procedure, Caster Option.
1. Check the location where the Cryochiller is to be placed.
Refer to Figure 3-1 on page 3-2 and Figure 3-2 on page 3-3 for placement and spacing
requirements.
Item Description
Electrical Category Type 1 – Equipment is fully de-energized
Tools Lift Device to lift, move, and place the unit -See Warning -
Heavy Object below
# 2 Phillips screwdriver
(2) 9/16-inch wrenches
Heavy Object
The refrigeration unit weighs more than 522 kg (1150 lb). Failure to
properly lift this device may result in death or serious injury.
• Use a fork lift or crane when lifting or moving the compressor
unit.
• If using lift ring option, refer to Appendix B: Lifting Rings
(Optional) on page 12-3
High Pressure Rupture
If a high pressure circuit is ruptured, equipment damage could
occur and cuts and eye injury from flying objects could cause death
or serious injury.
• Wear gloves and goggles when working around the Polycold
Cryochiller.
