4. Maintenance and Repair VX TopCooler
O-Ring Removal/Replacement/Cleaning Part Number: 606325 Rev. A
Thesystemmaybeusedinanenvironmentwherehazardousmaterialsarepresent,
andsurfacesmaybecontaminatedbythosematerials.

Whenthisisthecase,refertothefacility’sMaterialSafetyDataSheetsforthose
materialstodetermineproperhandlingandfollowthefacility’sprocedurestocertify
theenvironmentissafe.

Disposeofcleaningclothsperthefacility’sproceduresandlocalregulations.

MaintenanceProcedure
Step Action
1.
HOMEtherobotthenturnoffanddisconnectallpower,communications,andairconnectionsas
detailedintheShut-downsectionofthesystemmanual..
2.
Removal Procedure:
l
Usingthepick,prytheoldO-ringoutoftheO-ringgroovestartingattheplungehole.
l
OnceasectionoftheO-ringisfreeofthegroove,gentlyremovetherestoftheO-ringbyhand,
beingcarefulnottodamageorscratchtheO-ringorthesealarea.
NOTE: Use only a tool made of brass, plastic, or similar soft material. The O-ring groove is aluminum
and EXTREMELY sensitive to ANY small scratches left in the surface.
28
