Brother MFC-8690DW User Manual

Control panel setup
102
6
SES/WPS or AOSS™ (MFC-8690DW and MFC-8890DW wireless network only) 6
If your wireless access point supports either SecureEasySetup™, Wi-Fi Protected Setup (PBC
1
) or AOSS™
(one-push method), you can configure the machine easily without a computer. Your Brother machine has the
SES/WPS/AOSS™ menu on the control panel. This feature automatically detects which mode your access
point uses, SecureEasySetup™, Wi-Fi Protected Setup or AOSS™. By pushing a button on the wireless
access point/router and the machine, you can setup the wireless network and security settings. See the user’s
guide for your wireless access point/router for instructions on how to access one-push mode. (For more
information, see the Quick Setup Guide or Using the SES/WPS or AOSS™ control panel menu to configure
your machine for a wireless network (Automatic Wireless mode) on page 36.)
1
Push Button Configuration
WPS w/PIN Code (MFC-8690DW and MFC-8890DW wireless network only) 6
If your wireless access point supports Wi-Fi Protected Setup (PIN Method), you can configure the machine
easily without a computer. The PIN (Personal Identification Number) Method is one of the connection
methods developed by the Wi-Fi Alliance
®
. By inputting a PIN which is created by an Enrollee (your machine)
to the Registrar (a device that manages the wireless LAN), you can setup the wireless network and security
settings. See the user’s guide for your wireless access point/router for instructions on how to access the
Wi-Fi Protected Setup mode. (For more information, see Using the PIN Method of Wi-Fi Protected Setup
on page 39.)
WLAN Status (MFC-8690DW and MFC-8890DW wireless network only) 6
Status 6
This field displays the current wireless network status; Active(11b), Active(11g),
Wired LAN Active, WLAN OFF, AOSS Active or Connection Fail.
a Press Menu.
b Press a or b to choose Network.
Press OK.
c Press a or b to choose WLAN.
Press OK.
d Press a or b to choose WLAN Status.
Press OK.
e Press a or b to choose Status.
Press OK.
f The current wireless network status will be displayed; Active(11b), Active(11g),
Wired LAN Active, WLAN OFF, AOSS Active or Connection Fail.
g Press Stop/Exit.

Brother MFC-8690DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Copy Resolution	Up to 1200 x 600 dpi
Fax Modem Speed	33.6 Kbps
Mobile Printing	Yes
ADF Capacity	50 sheets
Maximum Paper Size	8.5" x 14" (Legal)
Operating System Compatibility	Windows, Mac OS, Linux
Scan Resolution	Up to 19200 x 19200 dpi (interpolated)
Copy Speed	Up to 32 cpm
Fax Resolution	Up to 203 x 392 dpi
Connectivity	Ethernet
Paper Capacity	250 sheets
Print Speed (Black)	Up to 32 ppm (Letter)
