Configuring your machine for a wireless network (For MFC-8690DW and MFC-8890DW)
32
3
1
WPA/WPA2-PSK is a Wi-Fi Protected Access Pre-Shared Key, which lets the Brother wireless machine associate with access points using
TKIP or AES encryption (WPA-Personal). WPA2-PSK (AES) and WPA-PSK (TKIP/AES) uses a Pre-Shared Key (PSK) that is 8 or more
characters in length, up to a maximum of 63 characters.
2
The WEP key is for 64-bit encrypted networks or 128-bit encrypted networks and can contain both numbers and letters. If you do not know
this information you should see the documentation provided with your access point or wireless router. This key is a 64-bit or 128-bit value
that must be entered in an ASCII or HEXADECIMAL format.
3
This is supported for WPA-PSK only.
4
Encryption key, WEP key, Passphrase. For LEAP and EAP-FAST, record the Name and Password.
For example: 3
b Plug the machine’s power cord into the AC power outlet. Turn on the machine’s power switch.
c Press Menu on the control panel of the Brother machine.
d Press a or b to choose Network.
Press OK.
e Press a or b to choose WLAN.
Press OK.
f Press a or b to choose Setup Wizard.
Press OK.
g If the following message appears, press a or b to choose On and press OK. The wired network interface
will become inactive with this setting.
72.WLAN
WLAN Enable ?
a On
b Off
Select ab or OK
For example:
64-bit ASCII: Uses 5 text characters e.g. “Hello” (this is case sensitive)
64-bit Hexadecimal: Uses 10 digits of hexadecimal data e.g. “71f2234aba”
128-bit ASCII: Uses 13 text characters e.g.
“Wirelesscomms” (this is case sensitive)
128-bit Hexadecimal: Uses 26 digits of hexadecimal data
e.g.“71f2234ab56cd709e5412aa3ba”
Network name:(SSID, ESSID)
HELLO
Communication Mode Authentication method Encryption mode Network key
Infrastructure WPA2-PSK AES 12345678
To Next Page
