Configuring your machine for a wireless network (For MFC-8690DW and MFC-8890DW)
33
3
h The machine will search for your network and display a list of available SSIDs. You should see the SSID
you wrote down earlier. If the machine finds more than one network use the a or b keys to choose your
network, then press OK. Go to step l.
If your access point is set to not broadcast the SSID, you will have to manually add the SSID name.
Go to step i.
i Choose <New SSID> using a or b.
Press OK. Go to step j.
72.WLAN
SSID
a <New SSID>
b
Select ab or OK
j Enter a new SSID name. (To manually enter the text, see Entering Text on page 225.)
Press OK.
72.WLAN
SSID:
Enter & OK Key
k Press a or b to choose Infrastructure.
Press OK. Go to step l.
If you chose Ad-hoc, go to step m.
72.WLAN
Mode Select
a Ad-hoc
b Infrastructure
Select ab or OK
l Choose the Authentication method using a or b, and press OK.
72.WLAN
Auth. Select
a Open System
b Shared Key
Select ab or OK
If you chose Open System, go to step m.
If you chose Shared Key, go to step n.
If you chose WPA/WPA2-PSK, go to step q.
If you chose LEAP, go to step r.
If you chose EAP-FAST/NONE, EAP-FAST/MSCHAP
1
or EAP-FAST/GTC, go to step q.
1
Shown on the LCD as EAP-FAST/MSCHAPv2.

Brother MFC-8690DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Copy Resolution	Up to 1200 x 600 dpi
Fax Modem Speed	33.6 Kbps
Mobile Printing	Yes
ADF Capacity	50 sheets
Maximum Paper Size	8.5" x 14" (Legal)
Operating System Compatibility	Windows, Mac OS, Linux
Scan Resolution	Up to 19200 x 19200 dpi (interpolated)
Copy Speed	Up to 32 cpm
Fax Resolution	Up to 203 x 392 dpi
Connectivity	Ethernet
Paper Capacity	250 sheets
Print Speed (Black)	Up to 32 ppm (Letter)
