Wireless configuration for Windows
®
using the Brother installer application (For MFC-8690DW and MFC-8890DW)
42
4
1
WPA/WPA2-PSK is a Wi-Fi Protected Access Pre-Shared Key, which lets the Brother wireless machine associate with access points using
TKIP or AES encryption (WPA-Personal). WPA2-PSK (AES) and WPA-PSK (TKIP/AES) uses a Pre-Shared Key (PSK) that is 8 or more
characters in length, up to a maximum of 63 characters.
2
The WEP key is for 64-bit encrypted networks or 128-bit encrypted networks and can contain both numbers and letters. If you do not know
this information you should see the documentation provided with your access point or wireless router. This key is a 64-bit or 128-bit value that
must be entered in an ASCII or HEXADECIMAL format.
3
This is supported for WPA-PSK only.
4
Encryption key, WEP key, Passphrase. For LEAP and EAP-FAST, record the Name and Password.
For example: 4
• If you have previously configured the wireless settings of the machine, you must reset the network LAN
settings before you can configure the wireless settings again. Press Menu, 7, 0 for Network Reset,
press 1 for Reset and then choose 1 for Yes to accept the change. The machine will restart automatically.
• If you are using Windows
®
Firewall or a firewall function of anti-spyware or antivirus applications,
temporarily disable them. Once you are sure that you can print, configure the software settings following
the instructions.
• You need to temporarily use an Ethernet cable during configuration. (The Ethernet cable is not a standard
accessory.)
For example:
64-bit ASCII: Uses 5 text characters e.g. “Hello” (this is case sensitive)
64-bit Hexadecimal: Uses 10 digits of hexadecimal data e.g. “71f2234aba”
128-bit ASCII: Uses 13 text characters e.g.
“Wirelesscomms” (this is case sensitive)
128-bit Hexadecimal: Uses 26 digits of hexadecimal data
e.g.“71f2234ab56cd709e5412aa3ba”
Network name:(SSID, ESSID)
HELLO
Communication Mode Authentication method Encryption mode Network key
Infrastructure WPA2-PSK AES 12345678

Brother MFC-8690DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 1200 x 1200 dpi
Duplex Printing	Yes
Copy Resolution	Up to 1200 x 600 dpi
Fax Modem Speed	33.6 Kbps
Mobile Printing	Yes
ADF Capacity	50 sheets
Maximum Paper Size	8.5" x 14" (Legal)
Operating System Compatibility	Windows, Mac OS, Linux
Scan Resolution	Up to 19200 x 19200 dpi (interpolated)
Copy Speed	Up to 32 cpm
Fax Resolution	Up to 203 x 392 dpi
Connectivity	Ethernet
Paper Capacity	250 sheets
Print Speed (Black)	Up to 32 ppm (Letter)
