Brother MFC-9130CW Service Manual

2-84
Confidential
4.2.4 Wrinkles on paper
<User Check>
- Check if the paper is loaded into the each paper tray correctly.
- Turn back the paper loaded in the paper tray or change the orientation of the paper by 180
°.
- Adjust the paper guide corresponding to the paper size.
- Check if the thickness of the paper is 60 to 105 g/m
2
.
(60 to 163 g/m
2
for manual feed slot.)
- Check if paper is not damp.
- Check that no dust adheres to the fuser unit.
- Check whether the paper type is appropriate.
4.2.5 Paper inclines diagonally
<User Check>
- Check if the paper is loaded into the each paper tray correctly.
- Adjust the paper guide corresponding to the paper size.
- Check if the thickness of the paper is 60 to 105 g/m
2
.
(60 to 163 g/m
2
for manual feed slot.)
- Check if too much paper is loaded in the tray.
Step Cause Remedy
1 Fuser unit failure Replace the fuser unit.
Step Cause Remedy
1 Registration clutch failure Replace the registration clutch.
2 Paper feed unit failure Replace the paper feed unit.
3 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9130CW Specifications

Printing

print speed black	up to 19 ppm
print speed color	up to 19 ppm
print resolution	up to 600 x 2400 dpi
print technology	Digital Color LED

Copying

copy speed black	up to 19 cpm
copy speed color	up to 19 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi

Faxing

fax modem	33.6 kbps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
large paper capacity	250-sheet capacity paper tray

Display

lcd display type/size	3.7” Color TouchScreen
touchscreen display size	3.7 inches

Memory

standard memory	192MB
maximum memory	192MB
