Brother MFC-9130CW Service Manual

4-11
Confidential
6. IF YOU REPLACE THE DOCUMENT
SCANNER UNIT, ADF UNIT (DUPLEX
SCANNING MODEL ONLY) OR CIS UNIT
■ What to do when replacing the document scanner unit, ADF unit or CIS unit
- Check of Main Firmware Version
- Acquisition of White Level Data (Function code 55)
6.1 Check of Main Firmware Version
Refer to "1.1.1 Checking firmware version" in this chapter and check the version of the main
firmware. If the main firmware is not the latest version, install the firmware.
6.2 Acquisition of White Level Data (Function code 55)
Perform the acquisition of white level data in accordance with "1.4.18 Acquisition of white level
data and setting of CIS scanning area" in Chapter 5.
Note:
If the firmware is not the latest version and it does not support the CIS unit, the scanned
image becomes all black.

Brother MFC-9130CW Specifications

Printing

print speed black	up to 19 ppm
print speed color	up to 19 ppm
print resolution	up to 600 x 2400 dpi
print technology	Digital Color LED

Copying

copy speed black	up to 19 cpm
copy speed color	up to 19 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi

Faxing

fax modem	33.6 kbps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
large paper capacity	250-sheet capacity paper tray

Display

lcd display type/size	3.7” Color TouchScreen
touchscreen display size	3.7 inches

Memory

standard memory	192MB
maximum memory	192MB
