Brother MFC-9130CW Service Manual

1-13
Confidential
1.8 FAX (Only for the models with FAX function)
Specifications are subject to change without notice.
1.9 Copy
Specifications are subject to change without notice.
Specifications are subject to change without notice.
Model
DCP-
9020CDN
DCP-
9020CDW
MFC-
9130CW
MFC-
9140CDN
MFC-
9330CDW
MFC-
9340CDW
Modem Speed
N/A 33,600 bps (FAX)
Transmission speed N/A Approximately 2 seconds
(ITU-T Test Chart #1, Std resolution, JBIG)
ITU-T group N/A Super G3
Color FAX Sending N/A
Receiving N/A
Internet FAX
(ITU T.37 simple mode)
N/A Yes (Download only)
Model DCP-9020CDN
DCP-9020CDW
Copy Speed (A4/Letter) Monochrome/Full Color: Up to 18/19 ppm
(for the U.S.A., Europe)
Monochrome/Full Color: Up to 22/23 ppm (for China)
First copy
out time
From Ready
mode and
Paper tray
Monochrome/Full Color: Less than 19/22 seconds
From Sleep
mode and
Paper tray
Monochrome/Full Color: Less than 35/38 seconds
Resolution 600 x 600 dpi
Auto duplex scanning copy N/A
Model
MFC-9130CW MFC-9140CDN MFC-9330CDW MFC-9340CDW
Copy Speed (A4/Letter) Monochrome/
Full Color: Up
to 18/19 ppm
Monochrome/Full Color: Up to 22/23 ppm
First copy
out time
From Ready
mode and
Paper tray
Monochrome/Full Color: Less than 19/22 seconds
From Sleep
mode and
Paper tray
Monochrome/Full Color: Less than 35/38 seconds
Resolution 600 x 600 dpi
Auto duplex scanning copy N/A Yes

Brother MFC-9130CW Specifications

Printing

print speed black	up to 19 ppm
print speed color	up to 19 ppm
print resolution	up to 600 x 2400 dpi
print technology	Digital Color LED

Copying

copy speed black	up to 19 cpm
copy speed color	up to 19 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi

Faxing

fax modem	33.6 kbps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
large paper capacity	250-sheet capacity paper tray

Display

lcd display type/size	3.7” Color TouchScreen
touchscreen display size	3.7 inches

Memory

standard memory	192MB
maximum memory	192MB
