Brother MFC-9130CW Service Manual

2-34
Confidential
4. TROUBLESHOOTING
4.1 Error Cause and Remedy
■ Error code 0100
ASIC error or motor driver error occurred.
■ Error code 0201
Synchronization signal from the main motor cannot be detected. Or the main motor speed is
unstable after a set period of time.
■ Error code 0202
Synchronization signal from the process motor cannot be detected. Or the process motor
speed is unstable after a set period of time.
Print Unable 01
Turn the power off and then back on again.
Step Cause Remedy
1 Main PCB failure Replace the main PCB ASSY.
Print Unable 02
Turn the power off and then back on again.
Step Cause Remedy
1 Main motor harness connection
failure
Check the main motor harness connection
and reconnect it.
2 Harness connection failure
between the low-voltage power
supply PCB and main PCB
Check the harness connection between
the low-voltage power supply PCB and
main PCB, and reconnect it.
3 Main motor failure Replace the process drive unit.
4 Low-voltage power supply PCB
failure
Replace the low-voltage power supply
PCB ASSY.
5 Main PCB failure Replace the main PCB ASSY.
Print Unable 02
Turn the power off and then back on again.
Step Cause Remedy
1 Process motor harness
connection failure
Check the process motor harness
connection and reconnect it.
2 Harness connection failure
between the low-voltage power
supply PCB and main PCB
Check the harness connection between
the low-voltage power supply PCB and
main PCB, and reconnect it.
3 Process motor failure Replace the process drive unit.
4 Low-voltage power supply PCB
failure
Replace the low-voltage power supply
PCB ASSY.
5 Main PCB failure Replace the main PCB ASSY.

Brother MFC-9130CW Specifications

Printing

print speed black	up to 19 ppm
print speed color	up to 19 ppm
print resolution	up to 600 x 2400 dpi
print technology	Digital Color LED

Copying

copy speed black	up to 19 cpm
copy speed color	up to 19 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi

Faxing

fax modem	33.6 kbps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
large paper capacity	250-sheet capacity paper tray

Display

lcd display type/size	3.7” Color TouchScreen
touchscreen display size	3.7 inches

Memory

standard memory	192MB
maximum memory	192MB
