Brother MFC-B7720DN Service Manual

1-4
Confidential
Model
MFC-L2715DW
MFC-L2716DW
MFC-L2717DW MFC-7890DN
MFC-L2730DW
MFC-L2732DW
MFC-7895DW
MFC-L2770DW
MFC-L2771DW
MFC-L2750DW
MFC-L2750DWXL
MFC-L2751DW
MFC-L2752DW
Wired/
Wireless LAN
Wired/Wireless Wired/Wireless Wired Wired/Wireless Wired/Wireless Wired/Wireless
Auto Duplex
Print

Duplex Scan N/A N/A N/A N/A

ADF

Auto Duplex
Copy
N/A N/A N/A N/A

Scanning
Method
CIS CIS CIS CIS Dual CIS Dual CIS
LCD Type
16 characters x
2 lines
(except for
KOR/TWN)
10 characters x
2 lines
(for KOR/TWN)
16 characters x
2 lines
10 characters x
2 lines
2.7" TFT
ColorLCD
(6.8 cm /
67.5 mm)
2.7" TFT
ColorLCD
(6.8 cm /
67.5 mm)
2.7" TFT
ColorLCD
(6.8 cm /
67.5 mm)
FB Up to A4/LTR Up to A4/LTR Up to A4/LTR Up to A4/LTR Up to A4/LTR Up to A4/LTR
FAX

NFC N/A N/A N/A N/A
Yes
(Link to
Solutions
Center /
Print&Scan /
Easy WLAN
setting)
Yes
(Link to
Solutions
Center /
Print&Scan /
Easy WLAN
setting)
USB Host
(front)
N/A N/A N/A N/A N/A N/A
USB Host
(rear)
N/A N/A N/A N/A N/A N/A
Emulation
PCL6, BR-
Script3, PDF
Version 1.7
N/A
PCL6, BR-
Script3, PDF
Version 1.7
PCL6, BR-
Script3, PDF
Version 1.7
PCL6, BR-
Script3, PDF
Version 1.7
PCL6, BR-
Script3, PDF
Version 1.7
Paper Input/
Standard Tray
250 sheets 250 sheets 250 sheets 250 sheets 250 sheets 250 sheets
Paper Input/
MP Tray
N/A N/A N/A N/A
30 sheets
Envelope:
2 envelopes
up to 0.23 mm
thick
N/A
Paper Input/
ADF
50 sheets 50 sheets 50 sheets 50 sheets 50 sheets 50 sheets
Paper Input/
Manual Feed
Slot
1 sheet 1 sheet 1 sheet 1 sheet
N/A 1 sheet
Specifications are subject to change without notice.

Brother MFC-B7720DN Specifications

General

Brand	Brother
Model	MFC-B7720DN
Category	All in One Printer
Language	English
