Brother MFC-B7720DN Service Manual

1-5
Confidential
Model
DCP-7090
DCP-7095D
DCP-B7500D
DCP-L2535D
DCP-L2536D
DCP-B7520DW
DCP-B7530DN
DCP-B7535DW
DCP-L2510D
DCP-L2511D
DCP-L2512D
DCP-L2530DW
DCP-L2531DW
DCP-L2532DW
Warm up Time
(From Sleep Mode)
Less than 9 sec. at 73.4F / 50% (23°C / 50%)
Warm up Time
(From Power ON)
Less than 27 sec.
at 73.4F / 50%
(23°C / 50%)
Less than 27 sec. at 73.4F /
50% (23°C / 50%)
(DCP-B7500D for ASA,
B7500D for CHN, L2535D
for ASA, L2536D for ASA)
Less than 28 sec. at 73.4F /
50% (23°C / 50%)
(DCP-B7520DW, B7530DN
for CHN, B7535DW)
Less than 27 sec.
at 73.4F / 50%
(23°C / 50%)
Less than 28 sec.
at 73.4F / 50%
(23°C / 50%)
FPOT
(From Ready Mode
and Standard Tray)
Less than 8.5 sec. at 73.4F (23°C) / 230V
FPOT
(From Sleep Mode
and Standard Tray)
Less than 17.5 sec. at 73.4F (23°C) / 230V
Mono Print Speed
(A4/Letter)
Up to 30/32 ppm
(Quiet Mode: Up to 13/13 ppm)
Up to 34/36 ppm
(Quiet Mode: Up to 13/13 ppm)
Up to 30/32 ppm
(Quiet Mode: Up to 13/13 ppm)
Full Color Print
Speed (A4/Letter)
N/A
Mono Duplex Print
Speed (A4/Letter)
N/A
16/17 sides per minute
(8/8.5 sheets per minute)
15/15 sides per minute
(7.5/7.5 sheets per minute)
Full Color Duplex Print
Speed (A4/Letter)
N/A
Processor 600 MHz
Back up Clock
N/A
Carton Dimensions
(W x D x H)
580 x 517 x 434 mm
22.8" x 20.4" x 17.1"
Machine Dimensions
(W x D x H)
410 x 398.5 x 272 mm
16.1" x 15.7" x 10.7"
410 x 398.5 x 272 mm
16.1" x 15.7" x 10.7"
(DCP-B7500D, L2535D,
L2536D, B7520DW)
410 x 398.5 x 318.5 mm
16.1" x 15.7" x 12.5"
(DCP-B7530DN, B7535DW)
410 x 398.5 x 272 mm
16.1" x 15.7" x 10.7"
Weight w/ Carton TBD
13.5 kg / 29.7 lb
(DCP-B7500D, L2535D,
B7520DW for CHN/LTN)
13.6 kg / 30.0 lb
(DCP-B7520DW for EU)
14.8 kg / 32.6 lb
(DCP-B7530DN, B7535DW)
13.1 kg / 28.9 lb
(DCP-L2510D)
13.4 kg / 29.5 lb
(DCP-L2512D)
TBD
(DCP-L2511D)
13.1 kg / 28.9 lb
(DCP-L2530DW for EU)
13.2 kg / 29.2 lb
(DCP-L2531DW)
13.4 kg / 29.6 lb
(DCP-L2532DW)
TBD
(DCP-L2530DW for LTN)
Weight w/o Carton,
w/ toner/drum
TBD
10.5 kg / 23.1 lb
(DCP-B7500D, L2535D,
B7520DW)
11.8 kg / 26.0 lb
(DCP-B7530DN, B7535DW)
TBD
(DCP-L2536D)
10.3 kg / 22.7 lb
(DCP-L2510D, L2512D)
TBD
(DCP-L2511D)
10.3 kg / 22.7 lb
(except for DCP-L2530DW
for LTN)
TBD
(DCP-L2530DW for LTN)
Weight w/o Carton
and toner/drum
TBD
9.2 kg / 20.3 lb
(DCP-L2535D)
9.4 kg / 20.7 lb
(DCP-B7520DW for
CHN/EU)
9.6 kg / 21.2 lb
(DCP-B7500D, B7520DW
for LTN)
10.9 kg / 24.0 lb
(DCP-B7530DN, B7535DW)
TBD
(DCP-L2536D)
9.2 kg / 20.3 lb
(DCP-L2510D, L2512D)
TBD
(DCP-L2511D)
9.2 kg / 20.3 lb
(DCP-L2530DW for EU,
L2532DW)
9.4 kg / 20.7 lb
(DCP-L2531DW)
TBD
(DCP-L2530DW for LTN)
Specifications are subject to change without notice.
