Chapter 2
44
Paper orientation using User Defined as the Paper Size in the printer driver 2
• When choosing Envelope in the Paper Thickness drop-down list, you must load the envelopes
in Portrait orientation.
• Tray #2 cannot be used for user defined paper sizes.
Paper weight and thickness 2
1
BP71 (260 g/m
2
) paper is especially designed for Brother inkjet machines.
User Defined Size Paper Orientation
Paper Tray #1 When both of the following conditions are satisfied:
Width: 148.0 mm – 215.9 mm
Height: 216.0 mm – 297.0 mm
Landscape
When any one of the following conditions is satisfied:
Width: less than 148.0 mm
Width: greater than 215.9 mm
Height: less than 216.0 mm
Height: greater than 297.0 mm
Portrait
Manual Feed Slot When both of the following conditions are satisfied:
Width: 127.0 mm – 215.9 mm
Height: 216.0 mm – 297.0 mm
Landscape
When any one of the following conditions is satisfied:
Width: less than 127.0 mm
Width: greater than 215.9 mm
Height: less than 216.0 mm
Height: greater than 297.0 mm
Portrait
Paper Type Weight Thickness
Cut-Sheet Plain Paper
64 to 120 g/m
2
0.08 to 0.15 mm
(Tray #2)
Plain Paper
64 to 105 g/m
2
0.08 to 0.15 mm
Inkjet Paper
64 to 200 g/m
2
0.08 to 0.25 mm
Glossy Paper
1
Up to 220 g/m
2
Up to 0.25 mm
Cards
Photo Card
1
Up to 220 g/m
2
Up to 0.25 mm
Index Card
Up to 120 g/m
2
Up to 0.15 mm
Envelopes
80 to 95 g/m
2
Up to 0.52 mm
Transparencies – –
