Brother MFC-J6935DW

3-91
Confidential
< 2.7 inch LCD model >
(1) Release the five Hooks and remove the Antistatic plate from the Key holder ASSY.
Fig. 3-101
(2) Remove the LCD back film from the Touch panel plate.
(3) Release the Hook and remove the Touch panel plate from the Panel upper cover.
Fig. 3-102
Hooks
Hooks
Hook
Antistatic plate
Key holder ASSY
Hook
LCD back film
Panel upper cover
2
3b
Touch panel plate
3a
