Brother MFC-J6935DW

3-109
Confidential
Assembling Note: When assembling the Flat cable of the Carriage PCB ASSY, be
careful about the front side and reverse side of the Flat cable.
Fig. 3-132
Routing of harnesses: See “ Main PCB/Modem PCB”, “ Head/carriage unit”.
Tube clamp
Flat cable of the
Carriage PCB ASSY
Carriage PCB ASSY
2
5
