Technical Data
20 E1400011_1_001
NormaI environmental conditions (CAN/CSA 61010-1-12; IEC 61010-1: 2010; ANSI/UL 61010-1)
• Indoor use only.
• Maximum operation altitude: 2000 m.
• Ideal operating temperature: 22-25 °C. Minimum operating temperature: 18°C maximum
operating temperature: 28°C humidity (non-condensing): 20-80%.
• Maximum relative humidity 80% for temperatures up to 31 or decreasing linearly to 50%
relative humidity at 40 °C.
• MAINS supply voltage fluctuations up to ±10% of the nominal voltage.
• TRANSIENT OVERVOLTAGES up to the levels of OVERVOLTAGE CATEGORY II.
• Pollution degree 2.
• Protection class IP20.
4.4 Rating Plate
The rating plate is located at the power input and includes the following information:
Figure4.1: The minispec MQ-Series Rating Plate
