The minispec Menu Functions
42 E1400011_1_001
Figure8.1: The Default View
The arrangement of the different bars supports an intuitive measurement handling.
8.2 The File Menu
The list of items in the Menu Bar depends on the active window. If the Signal Window is
active, and an application is loaded, all entries are visible. The functions of the menu can be
activated by a mouse click, or alternatively, using a keyboard shortcut (Alt + underlined
letter).
By activating the File menu all commands necessary for file handling are available (see
figure). Their use is in analogy to conventional Windows software, you can open, close, save
or print the contents of the selected windows (or the whole application).
Figure8.2: The File Pull-Down Menu
