The minispec Menu Functions
E1400011_1_001
49
The I/O Port Settings Command
One can connect serial interface devices, such as balances, thermostats or sample
changers, to the PC's communication port. To get the port configuration dialog, close all
minispec applications, then select I/O Port from the Setup menu. Note: To get the minispec
main menu, the R&D level or calibration permission must be given. Select the port
parameters according to the settings on the connected device.
The Licenses Command
Some special applications, like the digital pulse attenuation and the pulse shaping need to be
licensed. Use this menu to open the license number input box, which prompts the user to
input the license number. After a successful license procedure, the menu entry is checked
and grayed.
Have ready the minispec instrument's system number (see Status Bar) and contact BRUKER
for information or license numbers.
8.5 The Measurement Menu
All commands concerning the execution of measurements are concentrated in this menu item
(see the figure below). Since these commands are used frequently, quick select buttons are
available in the Measurement Tool Bar and key short cuts exist to enhance accessibility.
Figure8.7: The Measurement Pull-Down Menu
The Run, Stop and Continue Commands
The Run command starts a measurement. If the Sample Detector is set ON (see: Instrument
Settings Command) the measurement will be executed automatically with the insertion of the
sample.
Shortcuts: Standard Tool Bar:
Measurement Tool Bar:
Keys: ALT+M or ENTER
To interrupt a minispec measurement, use the Stop command.
Shortcuts: Standard Tool Bar:
