Bruker BioSpin minispec mq10 - Technical Data

Technical Data
E1400011_1_001
17
4 Technical Data
4.1 General Information
No. Series Type Weight
(kg)
Length
(cm)
Width
(cm)
Heigth
(cm)
1 mq-Series mq60 145 65 75 33
2 mq-Series mq40 145 65 75 33
3 mq-Series mq20 Airgap 33 mm* 145 65 75 33
4 mq-Series mq20 Airgap 25 mm* 135 65 75 33
5 mq-Series mq20 Toothpaste Analyzer 105 65 75 33
6 mq-Series mq10 135 65 75 33
7 mq-Series mq7.5 155 65 75 33
8 mq-Series mq20 Airgap 33 mm with PGU* 170 65 100 33
9 mq-Series mq20 Airgap 25 mm with PGU* 160 65 100 33
10 mq-Series mq10 with PGU 160 65 100 33
11 mq-Series mq7.5 with PGU 180 65 100 33
12 mq-Series PGU only 25 65 25 33
Table4.1: Technical Data: General Information
All specifications above are without the PC. Weights and dimensions apply to the
instruments, not to the packaged systems.
* For configurations with a high temperature probe, an additional table is used. However, this
table is not considered in the specifications provided.
