The minispec Menu Functions
E1400011_1_001
51
A flag in the Info Toolbar indicates a calibrated minispec application.
An uncalibrated minispec application is labeled with the following flag:
The Detect raw Signal Command
In some cases, for example to adjust the acquisition parameters, it might be helpful to detect
the signal without data processing. This command was implemented to execute only the
pulse sequence and acquisition without data processing or result output.
Shortcut: Keys: ALT+S
The Run Repetitive Command
With this command a measurement can be repeated several times at a regular interval.
Shortcut Keys: ALT+R
Select 'Repetitive Measurement Settings' from the Parameter menu to determine the
waiting time in seconds before a repetitive minispec measurement, the delay between two
successive repetitions, and the maximum number of repetitive measurements.
8.6 The Parameter Menu
All parameters for acquisitions, applications and repetitive measurements can be defined with
the assistance of the commands in this menu:
Figure8.8: The Parameter Pull-Down Menu
8.6.1 The Acquisition Parameter Table Command
Acquisition parameters are application dependent values (for example receiver gain, recycle
delay and number of scans to accumulate) that help define data acquisition. These values
can be modified when a minispec is connected to the PC and a minispec application has
been loaded. To modify acquisition parameters open the Acquisition Parameter Table.
Shortcuts: Standard Tool Bar:
Keys: ALT+P
To save the modifications to file, click <Save> before you leave the Parameter Table.
Note: Calibrated minispec applications will loose their calibration, if parameters are changed.
