Bruker D8 Series User Manual

Procedures
DOC-M88-EXX157_V17_04.2019 11 / 96
Table2.2: Instrument parameters for parallel beam systems with 40mm Göbel mirrors in primary TWIN /
TRIO optics
Instrument Parameter Value
Generator settings Cu: 40 mA / 40 kV
1), 2)
Co: 35 mA / 40 kV
1),2)
Radiation safety slit holder 1 mm
Göbel mirror with axial Soller slit 2.5°
Equatorial Soller slit 0.2°
1)
Valid for long fine focus X-ray tubes,
2)
In case of D8ADVANCEECO or
D8ENDEAVORECO Cu: 40kV/ 25mA ; Co: 35kV/ 28mA
Table2.3: Instrument parameters for parallel beam systems with 60mm Göbel mirrors
Instrument Parameter Value
Generator settings Cu: 40 mA / 40 kV
1) 2)
Co: 35 mA / 40 kV
1), 2)
Radiation safety slit holder 1.2 mm
Göbel mirror with axial Soller slit 2.5°
Equatorial Soller slit 0.2°
1)
Valid for long fine focus X-ray tubes,
2)
In case of D8ADVANCEECO or
D8ENDEAVORECO Cu: 40kV/ 25mA ; Co: 35kV/ 28mA
2.3 Measurement Parameters
Measurement parameters to be used are listed in the first table for Cu radiation and in the
second table for Co-radiation, respectively. Depending on specific measurement setups, indi-
vidual reflections may not be measurable. Continuous sample rotation speed of 15 rpm is
recommended. For statistical reasons each peak requires a minimum of 1000 counts at the
peak maximum, step times must be adjusted accordingly.
Table2.4: Measurement parameters for Cu radiation
Reflection
hkl
Scan angles 2θ [°]
1)
Step width 2θ [°]
1)
Step time [s]
1)
0 1 2 24.7 - 26.2 0.005 5
1 0 4 34.0 – 36.2 0.005 3
0 2 10 88.1 - 89.7 0.01 40
1 3 10 126.4 - 129.0 0.02 40
1)
For linear detectors measure all reflections in one uninterrupted range (from 20°to130°
in 2Theta) with smallest possible step width and step time 0.5s. For LYNXEYE/
LYNXEYEXE/ LYNXEYEXE‑T/ SSD160/ LYNXEYE‑2/ SSD160‑2 and
EIGER2R500K use step size of 0.005 and step time 0.5s. For evaluation limits use
values given as scan angles for point detector.
