Bruker D8 Series User Manual

G. Customer Acceptance Test Protocol
DOC-M88-EXX157_V17_04.2019 83 / 96
Part II: Angular Accuracy, Instrument Response and Resolution
Anode: Cu Parallel Beam Geometry
Angular Accuracy: Difference Deflection angle corr Instrument Response: I
rel
) Instrument Resolution
Maximum allowed 2θ deviation depends on height Maximum allowed intensity deviation for point detectors ± 10% FWHM
obs
< FWHM
max
2θ
obs
[°]
Differ-
ence
2θ
obs
Deflection
angle corr
Difference
Deflection
angle corr
2θ
exp
1)
[°]
I
obs
I
min
I
exp
1)
I
max
FWHM
obs
[°]
FWHM
max
2)
[°]
25.561 21.49 23.88 26.27
35.137 90.00 100.00 110.00
88.996 11.06 12.29 13.52
127.692 13.37 14.85 16.34
Deflection angle corr
½(Difference
max
+Difference
min
)
Detector
3)
Current Deflection angle Shift
2-Theta
3)
Corrected Deflection angle
(Current Deflection angle –
Deflection angle corr)
Height Maximum allowed shift 2θ [°] for specified accuracy of:
N: scaling factor; For details cf. chapter Reference Values [}15]
Vertical 150 0.02 ± 0.01°
obs:
observed
214 0.03 ± 0.015°
exp:
expected
258 0.04 ± 0.02°
corr:
corrected
Horizontal 214 0.02 ± 0.01°
rel: relative 258 0.02 ± 0.01°
1)
see table 3.1
2)
see table 3.3
3)
mark applicable: detector in case of Theta/Theta and 2-Theta in case of Theta/2Theta
Depending on specific measurement setups, individual reflections may not be measurable. Then measurements must be restricted to accessible reflections.
