What to do if the red ERR LED is on for Bruker IFS 125M Laboratory Equipment?
If the red ERR LED on the electronic mobile unit lights up, it indicates that strong mechanical shocks may have caused a temporary or permanent optics misalignment, or the HeNe laser might be defective. In this case, contact Bruker service for assistance.
Why is no interferogram observable on my Bruker IFS 125M Laboratory Equipment?
If no interferogram is observable, several issues could be the cause: * No optics connected. * OPUS status light is gray: check the optical bench URL. * Wrong measurement parameters: use the measurement parameters as described in appendix C. * Optical path blocked: check whether any accessory blocks the IR beam. * Detector not or incorrectly installed: check whether the detector is properly inserted into its holder. * No or wrong detector selected: select the correct detector on the OPUS Measure menu. * Wrong peak position saved: determine and save the correct peak position.
Why are all voltage status LEDs off on my Bruker IFS 125M?
If all voltage status LEDs are off, it could be due to several reasons: * The spectrometer is not turned on: Turn the main power switch to the 'ON' position. * The power cord is not connected: Connect the power cord to both the power outlet and the appliance inlet connector. * Voltage is not available: Verify that the proper voltage is supplied at the outlet.
What to do if the green RX LED is on but the yellow TX LED is off on Bruker Laboratory Equipment?
If the green RX LED is on while trying to establish a connection, but the yellow TX LED is off, it could be due to: * A wrong IP address assigned to the spectrometer: Assign the correct IP address to the spectrometer. * TCP/IP settings mismatch between spectrometer and computer/network: Refer to chapter 9.
Why is one voltage status LED off on my Bruker IFS 125M?
If one voltage status LED is off, it could be due to: * An external device shortening the power supply unit: Disconnect all external devices from the CAN bus or MPE port. * Temporary short circuit: Switch off the spectrometer, wait about 30 seconds, and switch it on again. * Defective LED: In this case, there is no spectrometer malfunction, and the spectrometer operates properly. The defective LED has to be replaced.
Why is the SR LED permanently on in my Bruker IFS 125M Laboratory Equipment?
If the SR LED is permanently on, it could be because: * The spectrometer is still in the initialization phase: Wait about 1 minute until the initialization procedure is completed. * The spectrometer control hangs: Reset the spectrometer using the RES button.
What to do if the temperature is out of range for Bruker IFS 125M Laboratory Equipment?
If the temperature is out of range, it means that the ambient temperature is too high. To resolve this, operate the spectrometer only within the ambient temperature range specified by the manufacturer (18 - 35°C).
How to fix buffer overflow in the optics controller of Bruker IFS 125M?
If a buffer overflow occurs in the optics controller, which indicates a severe problem in the data transfer from the DSP of the optics to OPUS, reduce the scanner velocity.
What does 'Scanner initialization mode' mean on Bruker IFS 125M Laboratory Equipment?
If the scanner is in initialization mode, this error message appears when you try to start a measurement while the spectrometer is still initializing. Wait until initialization has been finished.
Why is no signal detected in OPUS with my Bruker IFS 125M Laboratory Equipment?
If no signal is detected in OPUS, it indicates that the wrong OPUS parameters were selected. To fix this, select the correct OPUS parameters.
Provides an overview of the IFS 125M FT-IR spectrometer documentation and safety instruction classifications.
Details on safety precautions, observing instructions for user safety and property damage avoidance.
Explanation of various warning symbols and their meanings for safe operation.
Covers general operational information including protective earthing and personnel qualifications.
Instructions for connecting the spectrometer's power cord to an earthed socket for safety.
Describes the physical design features of the IFS 125M spectrometer.
Details the optical specifications and components of the spectrometer.
Explains the data acquisition process and hardware used by the spectrometer.
Lists the standard and optional components included with the IFS 125M spectrometer.
Specifies the environmental and electrical conditions needed for spectrometer installation.
Identifies and defines the various connection ports on the electronics unit.
Step-by-step guide for connecting the spectrometer to its power supply.
Instructions for correctly inserting the beamsplitter into the spectrometer.
Details and labels the components visible on the front of the spectrometer.
Describes the sample compartment and its use for accessories like gas cells.
Lists and describes different beamsplitter types, their spectral ranges, and part numbers.
Details important detector types used with the spectrometer, including spectral range and part numbers.
Explains the path of light through the spectrometer's optical system.
Highlights safety precautions related to laser radiation and high voltages during operation.
Describes the procedure for powering the spectrometer on and off using the main power switch.
Procedure for verifying signal detection and intensity after component replacement.
Guides on setting up and executing different types of spectroscopic measurements.
Instructions and handling advice for changing the spectrometer's beamsplitter.
Information on cooling the MCT detector using liquid nitrogen and its associated features.
Procedure for safely changing the detector in the spectrometer.
Outlines essential safety precautions and guidelines for performing maintenance procedures.
Procedure for checking laser signals to ensure proper scanning and path difference determination.
Steps to perform a quick check of laser signals using the OPUS software.
Detailed instructions for replacing the spectrometer's light source.
Procedure and guidelines for replacing optical windows in the spectrometer.
Instructions for preparing the spectrometer for transport, including cover removal.
Step-by-step guide on how to remove covers for maintenance or transport.
Procedure for safely moving and fixing the scanner during transport preparation.
Steps for re-installing the spectrometer after it has been transported.
Instructions for correctly remounting the scanning arm after transport.
Procedure for re-adjusting the fiber-coupling head for optimal laser signal alignment.
Provides a general procedure for diagnosing spectrometer problems and identifying causes.
Lists common error messages in OPUS, their possible causes, and troubleshooting steps.
Troubleshooting steps for when no interferogram is displayed in Check Signal mode.
Explains spectrometer issues indicated by various diagnostic LEDs on the electronics unit.
Details the meaning and troubleshooting for the ERR and SR diagnostic LEDs.
Troubleshooting for issues related to data transfer and connection problems.
Discusses access conflicts and control when connecting to the spectrometer via a network.
Overview of accessing and using the spectrometer's web-based diagnostic pages.
Explains how to send direct commands to the spectrometer via the web browser.
Provides a general overview of the spectrometer's functional state through diagnostic pages.
Details the laser's status, operational hours, and related diagnostics.
Describes how to generate and interpret a full report for instrument diagnostics.
Outlines possible configurations for connecting the spectrometer to a PC or network.
Step-by-step guide for setting up a direct connection to a standalone PC.
Details the standard and optional network addresses for spectrometer connectivity.
Instructions on how to assign new IP addresses to the spectrometer using FCONF.
Details the components and definitions of the ports on the flange panel.
Explains the electronic cable connections and LEDs for instrument diagnostics.
Provides further details and context regarding the spectrometer's resolution specifications.
Step-by-step guide for updating the spectrometer's firmware using the FCONF program.
Instructions on how to restore a previously backed-up firmware version.
General| Category | Laboratory Equipment |
|---|---|
| Software | OPUS |
| Type | FTIR Spectrometer |
| Detectors | DTGS, MCT |
| Light Source | Tungsten-Halogen |
| Interferometer Type | Michelson interferometer |
| Vacuum | Optional |
| Computer Interface | Ethernet |
