Bruker Optik GmbH IFS 125M User Manual
Description 4
4.5 Detector hoods
The spectrometer can accommodate up to 2 internal detectors. In the standard configu-
ration the spectrometer is equipped with a liquid N
2
-cooled MCT detector system for
MIR spectral range and high spectral sensitivity.
Apart from the standard detector there is a large number of optional detectors available.
All detectors are mounted on dovetail slides which allow an easy interchange.
4.5.1 Detector types
The following table contains the most important types of detectors to be used with the
spectrometer. For further detector options contact Bruker.
Figure 4.5a: Detector hoods mounted Figure 4.5b: Detector hoods removed
Description
Spectral region
a
(cm
-1
)
Part number
DLATGS 12,000 - 350 D301/3
InGaAs 12,800 - 5,800 D424/2
InSb, liquid-nitrogen
cooled
Harmful
➣ Observe the safety
instructions when cool
-
ing.
9,600 - 1,850 D413/2 (12 h)
D413-L/2 (24 h)
Table 4.4: Detector types
CAUTION
