Bruker Optik GmbH IFS 125M User Manual
Maintenance 6
6.7.5 Demounting complete scanning arm
1 Rotate the supporting feet far downwards.
➣ The supporting feet are located on the
bottom side of the detector and
interferometer block.
2
To further support the scanning arm it is advis-
able to push a piece of wood beneath the
scanning arm, close to the detector and inter
-
ferometer block.
Table 6.24: Transporting spectrometer - Demounting complete scanning arm
