176
IFS 125M User Manual Bruker Optik GmbH
Data Communication 9
9.2 Network addresses
Depending on the configuration type selected, use the IP addresses described in the fol-
lowing.
9.2.1 Standard configuration: connecting spectrometer to a stand-alone
PC
The spectrometer and the PC delivered by Bruker are configured for the stand-alone
operation, i.e. the correct network addresses have already been assinged to the spec
-
trometer and PC.
If you have not purchased the PC with Bruker, you have to assign the following network
addresses to the PC.
9.2.2 Optional configuration: spectrometer and PC connected to a
network
• Spectrometer and PC must have a unique IP address.
• IP address depends on the local intranet and must be assigned by the network
administrator.
• If the spectrometer is to be accessed via internet, you have to specify a gateway
address. The gateway links the intranet domain to other domains (e. g. internet
domains).
• If no gateway is defined, set the gateway address to 0.0.0.0.
• Do not specify a Gateway when using Windows XP as operating system.
Spectrometer PC Note
IP address 10.10.0.1 10.10.0.2 --
Subnet mask 255.255.255.0 255.255.255.252 --
Gateway 0.0.0.0 0.0.0.0 do not define when using
Windows XP
Table 9.2: Network addresses for standard configuration
