6.6 Checking drive cable
The drive cable for the moving mirror assembly must occasionally be checked for ten-
sion. Especially, when installing a new cable it is recommended to check the cable ten-
sion periodically to avoid slipping.
Definition
A Capstan
B Counter screw
C Thumb screw
Table 6.17: Parts of scanner drive cable unit
Figure 6.5: Scanner drive cable unit
A
B C
