Maintenance 6
6.5.1 Evacuating tools required
The evacuating equipment is not included in the delivery scope of the MCT detector.
Bruker offers evacuation equipment, and the service of evacuating (Part No: SD128). In
the latter you have to send the MCT detector to Bruker.
Tool Definition
Different pump models possible Turbo molecular pump/oil-free high-vac-
uum pump (which achieves an ultimate
vacuum of <10
-5
hPa)
Adapter
Adapter with flexible hose and flange:
• A: adapter
• B: flange
• C: flexible metal hose
• D: NW 25 flange
Table 6.14: Evacuation tools
A
B
C
D
