IFS 125M User Manual Bruker Optik GmbH
Connection Ports 10
10.4 Power supply panel
The power supply panel contains the power switch and voltage LEDs.
Component Definition
A Voltage LEDs
+5V, +12V, -
12V
These LEDs indicate the status of the secondary voltages
of the power supply unit.
i Any dark voltage LED indicates a major problem with
the spectrometer electronics.
Table 10.6: Ports and LEDs of power supply panel
Figure 10.4: Power supply panel
A
B
C
D
