IFS 125M User Manual Bruker Optik GmbH
Installation 3
3.5 Connection ports
The connection ports are located on the mobile electronics unit and electronics boxes.
Definition
A CAN bus connector
B Main power switch
C Low-voltage sockets (both ports are con-
nected via a y-cable)
D Ethernet port
Table 3.3: Connection port definition on electronics unit
Figure 3.1: Connection ports on electronics unit
A
B
C
D
C
