19
Bruker Optik GmbH IFS 125M User Manual
Installation 3
Power supply
a
:
The spectrometer power supply unit automatically
adapts to the most common power sources.
• Valid voltage range: 100 V AC to 240 V AC
• Valid frequency range: 50 to 60 Hz
• Additionally, any power supply via any 24 V DC
source is possible (load 5
A)
No uninterruptible power supply:
Property damage.
➣ Always ensure uninterruptible power supply (UPS)
and/or a line conditioner.
How to interrupt power
supply:
• Either switch off the spectrometer using the ON/OFF
switch, which is located on the front side of the
mobile electronics unit or
• unplug the power cable from the primary power
receptacle (AC inlet), which is located at the power
supply unit or
• unplug the power cable from the mains outlet
Space: • Stable and horizontal base which is able to bear the
weight of at least 160
kg
• For exact dimensions refer to appendix A.
Temperature variations: • Less than 1°C per hour and not more than 4°C per
day
• Avoid temperature variations as they can impair the
results of long-term measurements
Vibration: Do not locate the spectrometer in high traffic areas,
nor near vibration sources (ventilation hoods, air con
-
ditioners etc.).
a. If you connect external accessories to the spectrometer interface such as R232 (serial), Ethernet or
LPT1 (parallel), these accessories must comply with the requirements outlined in EN 61010 or EN
60950. This means that you always have to connect a SELV circuit (Safety Extra Low Voltage Circuit) to
a corresponding SELV circuit and not to any other circuit type.
Table 3.2: Site requirements
