Description 4
4.9 Mobile electronics unit
The spectrometer is equipped with a mobile electronics unit. This unit is connected to
the spectrometer via several cables and consists of different panels.
4.9.1 Panel types
The following table contains the different types of panels. A detailed description of the
single panels is given in chapter
10.
Figure 4.9: Mobile electronics unit
Panel type Location on front side of the electronics unit
Flange panel
Table 4.5: Panel types
