Bruker D8 Series User Manual

Reference Values
DOC-M88-EXX157_V17_04.2019 17 / 96
3. The deflection angle must be saved to data base of the MEASUREMENT SUITE by the
Save configuration to data base of the Configuration plugin.
´ The software will ask for a name for this configuration. The name is Instrument
Verification Factory. Saving will update the older factory configuration defined with
basic setup.
4. Save and activate this setting.
3.1.3 Factory and Customer Acceptance Test Protocol
The deviation is given by the angular difference between measured peak position and refer-
ence value given in Table 3.1 and Table 3.2.
The shift is defined as the difference between minimum and maximum deviation. If the shift is
within the allowed range but the deviation is out the specified value, offset is corrected. This
ensures that the deviations are in the specified accuracy specifications.
The accuracy of the tested equipment is the maximum measured deviation after offset cor-
rection.
The configuration must be saved to the database:
1. Insert Instrument Verification Factory / Customer, when asked for a configuration
name by the software.
2. Save and activate this setting.
3.2 Instrument Resolution
Maximum values for line shape in terms of FWHM (Full Width at Half Maximum) are listed in
the following two tables. Please note, that these values are dependent on the instrument ge-
ometry, on the detector type, and on the anode material employed.
Table3.3: Maximum allowed values for the line shape in terms of FWHM (Cu-radiation). SC: scintillation
counter, SOL‑XE: energy dispersive solid state detector, position sensitive detector VÅNTEC‑1,
SSD160, LYNXEYE/ LYNXEYEXE/ LYNXEYEXE‑T, LYNXEYE-2, SSD160-2 and EIGER2R500K
Reflection
hkl
Bragg-Brentano Parallel Beam
(Göbel Mirror)
SC/ SOL‑XE
[°]
VÅNTEC‑1
[°]
LYNXEYE/
LYNXEYEXE/
LYNXEYEXE‑T/
SSD160/
LYNXEYE‑2/
SSD160-2
EIGER2R500K
[°]
SC / SOL‑XE/
LYNXEYE/
LYNXEYEXE/
LYNXEYEXE‑T/
SSD160/
LYNXEYE‑2/
SSD160-2
1)
EIGER2R500K
2)
[°]
0 1 2 0.055 0.07 0.06 0.22
1 0 4 0.055 0.07 0.06 0.22
0 2 10 0.10 0.10 0.10 0.22
1 3 10 0.18 0.18 0.18 0.27
1)
LYNXEYE / LYNXEYEXE/ LYNXEYEXE‑T / SSD160/ LYNXEYE‑2/ SSD160‑2 in 0D
mode
2)
EIGER2R500K in 0D mode with 14mm*16mm opening
