1 Introduction
This guidance outlines procedures recommended by Bruker AXS for instrument verification.
The procedures described apply to all Bruker AXS D8 ADVANCE, D8 DISCOVER, and
D8 ENDEAVOR diffraction systems used for X-ray powder diffraction analysis in reflection
mode and fully cover the functionality of all validation relevant components of these diffraction
systems as provided in the following table.
Table1.1: Diffraction systems and verification relevant components. Some combinations of accessories might not be
available. For details refer to the detailed tables in section Appendices A to I [ } 20]
Bragg-Brentano Systems Parallel Beam Systems
Diffractometer D8 ADVANCE
1)
D8 DISCOVER
D8 ENDEAVOR
2)
D8 ADVANCE
1)
D8 DISCOVER
Anode Cu, Co Cu, Co Cu, Co
Goniometer Theta / 2Theta
Theta / Theta
Theta / Theta Theta / 2Theta
Theta / Theta
Sample stage Standard
Rotating
FLIP-STICK
AUTO CHANGER
Centric Eulerian cradle
Compact cradle
Compact cradle
plus
UMC 150, UMC 150 HTS,
UMC 151, UMC 1516
Compact UMC
Rotating Standard
Rotating
FLIP-STICK
AUTO CHANGER
Centric Eulerian cradle
Compact cradle
Compact cradle
plus
UMC 150, UMC 150 HTS,
UMC 151, UMC 1516
Compact UMC
Monochromati-
sation:
Focusing monochromator
Secondary monochromator
Kβ-Filter
Discriminator settings
(LYNXEYEXE-T)
Kβ-Filter
Discriminator settings
(LYNXEYEXE-T)
Primary Göbel mirror
(60mm)
Primary TWIN / TRIO
optics
Discriminator settings
(LYNXEYEXE-T)
Slits: Fixed divergence and
antiscatter slits
Variable divergence and
antiscatter slits
Variable divergence slit
and air scatter screen
Fixed divergence slit and
air scatter screen
Primary axial Soller slit
Secondary axial Soller slit
Receiving slit
TWIN / TRIO optics
Fixed or variable
divergence slit
3)
Fixed divergence slit and
air scatter screen
4)
Variable divergence slit
and air scatter screen
4)
Primary axial Soller slit
Secondary axial Soller slit
Fixed slits
Primary axial Soller slit
Secondary equatorial
Soller slit
Secondary TWIN optics of
the PATHFINDER
