WZR-HP-AG300H User Manual 14
Chapter 2 - Placing Your AirStation
Vertical Placement
If the AirStation is to be placed vertically, attach the stand as shown.
Horizontal Placement
When installing the AirStation horizontally, attach the stand for best heat dissipation.
1
Attach the stand as shown in the gure.
