Burdick ELI 280 - Rear View; Base View

INTRODUCTION
24
Rear View
Figure 1-3
1 2 3 4 5 6 7
1 AM12 ECG connector port
2 USB device port
3 USB connector port
4 RJ45 LAN connector port
5 Modem port
6 WLAN antenna connector
7 100 – 240V power
Base View
Figure 1-4
Battery Compartment
