INTRODUCTION
28
Specifications
Feature
Specifications
Instrument Type
Multi-lead electrocardiograph
Input Channels
Simultaneous acquisition of all 12 leads
Standard Leads Acquired
I, II, III, aVR, aVL, aVF, V1, V2, V3, V4, V5, V6
Waveform Display
Backlit, 10.1” high-resolution color LCD
Input Impedance
Input Dynamic Range
Electrode Offset Tolerance
Common Mode Rejection
Pacemaker Pulse Display
Meets or exceeds the requirements of ANSI/AAMI/ IEC
60601-2-25
Patient Leakage Current
Chassis Leakage Current
Meets or exceeds the requirements of ANSI/AAMI ES1
Digital Sampling Rate
40,000 s/sec/channel used for pacemaker spike detection;
1000 s/sec/channel used for recording and analysis
Optional Functions
Mortara VERITAS resting ECG interpretation algorithm with age and
gender specific criteria; connectivity with bidirectional communication
Paper
Perforated Z-fold thermal paper, Smart, A4 or 8.5 x 11” wide, 250
sheets
Thermal Printer
Computer-controlled dot array; 1 dot/ms horizontal, 8 dots/mm vertical
Thermal Printer Speeds
5, 10, 25, or 50 mm/s
Gain Settings
5, 10, or 20 mm/mV
Report Print Formats
Standard or Cabrera: 3+1, 3+3, 6, 6+6, or 12 channel
Rhythm Print Formats
3, 6, 8 or 12 channel with configurable lead groups
Frequency Response
0.05 to 300 Hz
Filters
High-performance baseline filter; AC interference filter 50/60 Hz; low-pass
filters 40 Hz, 150 Hz, or 300 Hz
A/D Conversion
20 bits (1.17 microvolt LSB)
Device Classification
Class I, Type CF defibrillation-proof applied parts
ECG Storage
Internal storage up to 40 ECGs; optional expanded up to 200 ECGs
Weight
12.5 lbs. (5.68 kg) including battery (without paper)
Dimensions
17.5 x 15.5 x 4.5” (44.45 x 39.37 x 11.43 cm)
Power Requirements
Universal AC power supply (100-240 VAC at 50/60 Hz) 110 VA; internal
rechargeable battery
