Reviewing ECG Records
To review an existing patient ECG record:
1. Select from the real-time display, followed by Directory.
2. Navigate to the desired patient record, and select.
3. Select the desired acquired ECG from the sub directory.
4. Once selected the acquired ECG will display.
5. To change the format of the acquired ECG touch the display and select the desired settings for Print
Format, Print Speed, Print Gain, Print Filter and Pacer channel.
6. Select OK to save and return to ECG display, or Cancel to exit without saving.
7. To view the interpretation, select . Select again to return to the displayed ECG.
8. Select Print to print the acquired ECG; use Stop to stop printing. To transmit the acquired ECG use
Send; to delete use Erase.
9. Select ID to enter or edit demographic information (if required) after ECG acquisition.
10. Select Back to return to the sub directory. Select Back again to return to the ECG directory.
To acquire an additional ECG using the existing demographics:
1. Navigate to the sub directory for the desired patient.
2. Select New ECG followed by Done.
3. To acquire the new ECG, select . Once completed, the acquired ECG displays on a red grid
background.
4. Change the format by touching the display and selecting the desired settings for print format, print speed,
print gain, print filter, pacer channel and Best 10/Last 10. Select OK or Cancel to save or discard the
changes. With the tracings displayed you can select print, send, or erase the new ECG record.
5. Use Done to save the new record and return to the sub directory.
