Technicaldata


ThedevicesapprovedbyCSA,withvariablekeyPD01,conformto
thefollowingstandards:
CSAC22.2n°61010-1-04•
UL61010-1•


PCorPSU
PA6orPPS
EPDM
PAorPVDF
Stainlesssteelor
brass
Brass
Materials used in the 1062 position feedbackFig. 3
 
Housing/Cover PA6/PCor
PPS/PSU
Sealbetweenthecoverandthe
housing
EPDM
 
CableglandM16x1,5 PAorPVDF
Externalthreadedpart Brassorstainlesssteel
Internalthreadedpart Brass
M16x1,5
67,5 35
Ø 66
M5 / M6 / M10
12 / 10 / 16
M24x1,5 / M26x1,5 / M36x2
87
72
24 - 40
SW27
Dimensions of the 1062 position feedback [mm]Fig. 4
