Burkert 1062 - Fitting with Stroke Limiter (50-80 mm)

19

English
Assembly
Fullytightentheduplicationrodon→
theactuatorrodusingascrewdriver
withabladeofsuitablesize.
Depressurizetheactuatorofavalve
→
whichisnormallyclosed(function
"A")orhasadoubleeffect(function
"I"):thevalverecoversitsdefault
position.
C
D
Insertthepositionfeedbackhousing→
intotheduplicationsystem"D"
settingthecableglandinthe
directiondesiredandmakingsure,
onamechanicalcontactversion,
thatyoudonotdamagethecontact
leversontheswitches.
Fastenthehousingandthedupli-
→
cationsystembytighteningthecone
pointsetscrew"C"usingahexa-
gonalmalespanner.
K
L
Unscrewthecover"K"onthe
→
positionfeedback.
Unscrewthecablegland"L".
→
Threadthecablethroughthecable→
gland.
Wireaccordingtothewiring
→
diagramforyourversionofthe1062:
SeeChapter8.
Fastenthecableglandtoensure
→
tightnessoftheproduct.






Preventtheprojectionoffluidsintotheactuator.•


Preventtheprojectionoffluidsintothepositionfeedback.•
