Burkert 1062 - Page 18

18

English
Assembly
D
J
E
H
Checkthattheseal"H"isfittedand→
thatitiscorrectlypositionedinside
theactuator.
Inserttheduplicationsystem"D"into
→
theactuator.
Screwtheduplicationrod"E"onto
→
theactuatorrod"J".
Tightentheadaptoruntilfreecontact→
isobtainedwiththetopofthe
actuator,usingaflatNo27spanner.
E
Checkthatthesealshavebeenfitted→
andthattheyareundamaged.Replace
themifnecessary.
Putthreadlockintotheinternalthread
→
intheduplicationrod"E".
F
G
Unscrewthesmalltransparentcap"F"→
ontheactuator,preferablybyhandor
using a suitabletool in order notto
damageit (except for actuatorssize
40mm).
Pumpairintotheactuatoronavalve
→
whichisnormallyclosed(function"A")
orhasadoubleeffect(function"I")so
thattheactuatorrodmovestothetop
position.
Unscrewthevisualpositionfeedback
→
"G"usingahexagonalmalespanner.
